TK-5220 / 5320

KENWOOD TK-5220

TK-5220 / 5320

  • Description
  • Performance Characteristics
  • Physical Characteristics
  • User Environment

KENWOOD's VHF and UHF P25 Portable Radios feature a compact, rugged design rich with capability and performance. The new TK-5220/5320 portables join KENWOOD's higher tier P25 radio models to offer an expanded group of P25 solutions for all levels of public safety and service agencies. These new mid-tier P25 models operate in FM Analog and P25 Digital modes and combine AMBE + 2 Enhanced Full Rate Vocoder tehcnology along with KENWOOD's decades of audio heritage to deliver unmatched audio performance in a two-way radio.

Frequency Band:
VHF/UHF

Frequency Range:
136-174 MHz / 450-520 MHz, 400-470 MHz

Power Output:
5W

Standard battery chemistry type:
Li-ion

Battery life (based on a 5-5-90 duty cycle):
12.5 hours

Number of Channels/Groups/Zones:
512 Channels / 128 Zones

Channel spacing:
12.5 / 15 / 25 / 30 kHz Analog
12.5 kHz Digital

Dimensions W x H x D (with standard battery)
2.28 x 5.20 x 1.63 in

Weight (with standard battery)
13.23 oz

Keypad / Keys
12-Keypad Models

Display
14 Character Alphanumeric Aliases
3-Digit Sub-Display

Operating temperature
-22°F to +140°F

Mil spec
MIL-STD-810 C/D/E/F/G

IP Standards
IP54/55/67/68

  • Analog FleetSync/II or MDC-1200 (one format per radio)
  • 14 Character Alphanumeric lighted dot matrix LCD
  • 16-Position Selector Knob with detent feel & mechanical stop
  • 8 Programmable Function/LCD menu keys
  • RSSI Indicator
  • Transmit/Busy/Call Alert/Warn LED
  • 3-Digit Sub-Display*
  • 12-Keypad Models
  • VOX Ready
  • Emergency Features
  • Transceiver Password
  • Easy Option Port
  • Voice Guide & Storage (Option)
  • MIL-STD 810 C/D/E/F
  • IP 54/55 Water & Dust Intrusion
  • Single Zone/Multi-Zone Scan
  • Dual Priority Scan
  • Intrinsically Safe Option

Analog Features

  • QT/DQT
  • 2-Tone Decode/Encode
  • DTMF Encode/Decode/Stun
  • Companded Audio
  • FleetSync / II (FM)
  • PTT ID Digital ANI
  • Status Messaging
  • Caller ID Display
  • Send/Display GPS (KPG-47GPS)
  • Selective & Group Call
  • Emergency & Stun Statuses

MDC-1200 Feature

  • PTT ID Digital ANI
  • Caller ID Display
  • Emergency Status
  • Radio Check
  • Radio Inhibit

P25 Digital Feature

  • P25 Digital Conventional
  • AMBE+2 Enhanced Vocoder
  • Talk Group ID Lists
  • Individual ID Lists
  • Caller ID Display
  • Encryption Key Zeroize and Retention
  • DES Encryption Module
  • AES & DES Encryption Module

Antenna [+]

KRA-16

KRA-16

VHF Stubby Antenna
KRA-17

KRA-17

UHF Stubby Antenna
KRA-22M

KRA-22M

VHF low-profile antenna 148-162 MHz
KRA-22M2

KRA-22M

VHF low-profile antenna 162-174 MHz
KRA-22M3

KRA-22M

VHF Low-profile helical antenna 136-150 MHz
KRA-23M

KRA-23M

UHF low-profile antenna 450-490 MHz
KRA-23M3

KRA-23M3

UHF Low-profile helical antenna 403-430 MHz
KRA-25

KRA-25

High gain VHF helically loaded whip antenna 148-162 MHz
KRA-26M

KRA-26M

VHF helical antenna 146-162 MHz
KRA-26M2

KRA-26M2

VHF helical antenna 162-174 MHz
KRA-26M3

KRA-26M3

VHF helical antenna 136-150 MHz
KRA-27M

KRA-27M

UHF whip antenna 440-490 MHz
KRA-27M2

KRA-27M2

UHF whip antenna 470-520 MHz

Batteries and Charging [+]

KBP-7

KBP-7

AA Alkaline Refillable Battery Pack (6 AA; 9V) cells not included
Note: the color of the case is orange
KNB-47

KNB-47L

1950 mAh, Li-ion battery - requires KSC-32/326K/326AK charger
KNB-48

KNB-48L

2550 mAh, Li-ion battery - requires KSC-32/326K/326AK charger
KNB-50

KNB-50NC

2000 mAh, Ni-MH battery - requires KSC-32/326K/326AK charger [CSA-us Intrinsically Safe Option]
Note: FM Intrinsically Safe Option and repairs for FM-certified radio are no longer available. Once repaired, radio loses FM certification and is required to be recertified to CSA-us to maintain the IS rating.
KSC-32

KSC-32

Rapid-rate single-unit charger for KNB-31A/32N/33L/41NC/43L/47L/48L/50NC
Note: Includes 110/220V auto-switching AC adapter with U.S.-style line cord plug; requires plug adapter for 220V Euro-style outlets (not supplied).
KSC-326

KSC-326

Rapid-rate 6-unit charger
KVC-15

KVC-15

Rapid-rate DC vehicular charger adapter for the KSC-32 (chargers not included; includes KSC-mobile bracket & cigarette lighter cable DC adapter)
No Image Available

KVC-20

D.C. Vehicular Charger Li-ion/Polymer

Carry Accessories [+]

KBH-10

KBH-11

Spring action belt clip (2.5")

Microphones and Audio Accessories [+]

KEP-1

KEP-1

3.5mm earphone kit for KMC-48GPS Speaker Mics
No Image Available

KHS-11BL

2-wire palm mic w/earphone, universal connector (Black) [Intrinsically Safe Approved Accessory]
No Image Available

KHS-12BL

3-wire mini lapel mic w/earphone, universal connector (Black) [Intrinsically Safe Approved Accessory]
No Image Available

KHS-14

Lightweight Single muff headset w/boom mic & In-line PTT [Intrinsically Safe Approved Accessory]
No Image Available

KHS-15-BH

Heavy-duty noise reduction behind-the-headset w/noise canceling boom mic & in-line PTT [Intrinsically Safe Approved Accessory]
No Image Available

KHS-15-OH

Heavy-duty noise reduction over-the-headset w/noise canceling boom mic & in-line PTT [Intrinsically Safe Approved Accessory]
No Image Available

KMC-38

GPS Speaker Microphone
No Image Available

KMC-41M

MIL-SPEC, IP54/55 Noise-canceling Speaker Mic [Intrinsically Safe Approved Accessory]
